Heavy Duty LD Series is the Premiere
Double Seal Sanitary Pump

Ampco’s LD Series is a close-coupled version of the LC Series utilizing a double mechanical seal. This simplistic, hardworking centrifugal pump is exclusive to Ampco Pumps.

Cast and machined from 316L stainless steel and offering a 304 stainless steel adapter, the LD Series double seal design expertly handles sticky, abrasive and sugary products. The pumps use a buffer fluid and is designed to be easier to maintain because of its fewer components.

The LD is commonly used with abrasive or volatile products, and in vacuum applications.

LD Series
Centrifugal Pump Features

• 316L Stainless Steel Heavy Wall Construction
• Cast and Machined
• 304 Stainless Steel Adapter
• Balanced Impellers
• 316L Stainless Steel Shaft
• Easy to Maintain with Less Components

LD Series Performance Overview

Models:  15
Max Inlet Pressure:  150 PSI / 10 BAR
Max Flow Rate:  800 GPM / 182 mᵌ/hr
Max Viscosity:  1,200 cP
Seal Specifications:  3 Seal Options
